7.5kw Small Type Portable Air Compressors Direct Driven
We will try our best to provide customers with better Belt Driven Piston 1.5KW to 15KW, Oil-less Piston Air Compressor 4KW, Oil Separators Filter Used in Compressor and services with more enthusiasm and more efficient measurements. Over the years, we have won the trust of users by virtue of excellent performance, pragmatic and enterprising business philosophy, and the business tenet of high-quality products, timely delivery, low prices and satisfactory service. We have always won the trust of a large number of customers with the attitude of working diligently and sincerely treating others, and carefully paying attention to every production detail, and our products are sold well at home and abroad.
Basic Info
●Model NO.: HD0208
●Type: Piston –Belt Driven
●Performance: Low Noise
●Drive Mode: Electric
●Power Source: AC Power
●Configuration: Stationary
●Material: Aluminum
●Piston Type: Closed
●Lubrication Style: Lubricated
●Mute: Not Mute
●Driven Method: Belt Driven:
●Brand: OEM Can Be Provided
●Trademark: HighQ
●Specification: CE TUV
●Origin: China
●HS Code: 8414809090
Product Description
●With over 20 years of experience at the forefront air compressor manufacturing, the range of products and services that we offer encompasses innovative design with high quality construction backed up with the high level of product support and after sales service.
●This dedication to quality and innovation allows us to deliver the value, reliability, convenience and efficiency that our thousands of customers demand.
●With a warranty and provide a reliable and robust solution for workshop and light industrial applications.
●We mainly export high quality and efficiency air compressors ,our compressors with the advantage of low noise ,energy saving and reliable performance.
Parameter & Specification
Model | Motor Power (kw/hp) | Cylinder (diameter x Piece) | Exhaust volume m³/min | Working Pressure (Mpa) | RPM(r/min) | Dimension (LxWxH cm) | Weight (kg) |
HD0208 | 2.2/3 | 55x2 | 0.25 | 0.7 | 800 | 27x27x30 | 20 |
HD2055 | 3/4 | 65x2 | 0.36 | 0.7 | 820 | 29x30x39 | 15 |
Z-0.036/7 | 0.55/0.75 | 51x1 | 0.005 | 0.7 | 800 | 23x15x27 | 8 |
V-0.08/7 | 0.75/1 | 51x2 | 0.08 | 0.7 | 800 | 95x25x31 | 18 |
Z-0.10/7 | 1.5/2 | 55x1 | 0.1 | 0.7 | 800 | 27x23x34 | 20 |
V-0.12/7 | 1.1/1.5 | 51x2 | 0.12 | 0.7 | 800 | 35x74x29.5 | 18 |
V-0.17/7 | 1.5/2 | 51x2 | 0.17 | 0.7 | 950 | 36x25x33 | 20 |
V-0.25/7 | 2.2/3 | 55x2 | 0.25 | 0.7 | 820 | 41x27x36 | 22 |
W-0.38/7 | 3/4 | 65x3 | 0.58 | 0.7 | 800 | 46.5x27x37 | 28 |
V-0.48/7 | 4/5.5 | 90x2 | 0.48 | 0.7 | 820 | 53x30x40 | 54 |
W-0.67/7 | 5.5/7.5 | 80x3 | 0.57 | 0.7 | 800 | 52x43x52.5 | 68 |
W-0.9/7 | 7.5/10 | 90x3 | 0.9 | 0.7 | 800 | 93.5x43x52.5 | 73 |
W-1.4/7 | 11/15 | 100x3 | 1.4 | 0.7 | 780 | 70x62x55 | 180 |
W-1.8/7 | 15/20 | 120x3 | 1.8 | 1.25 | 780 | 93x55x110 | 210 |
V-0.15/12.5 | 1.5/2 | 65x1/51x1 | 0.15 | 1.25 | 950 | 96x25x32 | 20 |
V-0.20/12.5 | 2.2/3 | 65x1/51x1 | 0.2 | 1.25 | 820 | 41x27x36 | 22 |
W-0.30/12.5 | 3/4 | 65x2/51x1 | 0.3 | 1.25 | 800 | 46.8x20x38 | 28 |
W-0.53/12.5 | 5.5/7.5 | 60x2/65x1 | 0.53 | 1.25 | 860 | 62x42x52.5 | 68 |
W-0.71/12.5 | 7.5/10 | 50x2/90x1 | 0.71 | 1.25 | 800 | 62x43x52.8 | 73 |
W-1.05/12.5 | 11/15 | 100x2/90x1 | 1.05 | 1.25 | 780 | 76x62x88 | 130 |
W-1.50/12.5 | 16/20 | 120x2/100x1 | 1.5 | 1.25 | 780 | 93x56x90 | 210 |
With over 20 years' experience, HighQ Compressor is specialized in manufacturing and marketing direct driven piston 0.55kw to 2.2kw, which is of high efficiency, low energy consumption and long lifespan. As one of the professional manufacturers and suppliers in China, we warmly welcome you to buy quality equipment made in China from our factory.
Our company devotes itself to design and development, and constantly adopts international advanced technology to develop various series of 7.5kw Small Type Portable Air Compressors Direct Driven, which are unique in the domestic technical level. Our company has a large number of high-quality talents, scientific and reasonable management mechanism, and strict control of the production process, which have laid a solid foundation for the development of the enterprise. We will perform our best to continue to improve all our product series so that the performance level, productivity and quality standards of our products reach international standards.
