HighQ 7bar Screw Compressor-Direct
HighQ warrants this product to the end-user, when properly installed and under normal conditions of use, to be free from defects in workmanship and materials for a period of one year from the provided date of purchase for the original purchaser of the product.
Product Detail
●Model NO.: HQ-50D
●Type: Screw
●Performance: Low Noise
●Drive Mode: Electric
●Power Source: AC Power
●Configuration: Stationary
●Material: Cast Iron
●Lubrication Style: Oil-less
●Air Flower :6.6-4.8m3/Min
Work Pressure 7-13bar
●Performance :Low Noise Export Markets :Global
●Type:Direct: Power Source :AC Power
●Trademark: HighQ
●Specification: CE TUV
●Origin: China
●HS Code: 8414809090
Product Description
Features,
high-qualityhigh efficiency Low noise energy saving
1-Air -End Made in German. GHH-RAND and ROTORCOMP VERDICHIER GmbH. To assure its excellent performance Recognized throughout the world as a superior air-end because of it's superior performance under all conditions and they are recognized as the worlds best Air End being used in other major brand names- German made
2- Ally-win air end from Germany, the most advanced airend in the world.
3 - Original imported key components
4- Low Energy Consumption,Low running,maintenance cost.
5- Unique safe units make whole compressor more safety, more stable,lest noise,lest energy Loss.
6- Easy to install,operate,maintain.
Model | HQ-30D | HQ-50D | HQ-60D | HQ-75D | HQ-100D | HQ-125D | HQ-150D | HQ-175D | HQ-200D | HQ-250D | HQ-285D | HQ-300D | HQ-350D | HQ-380D | |
Air Delivery/Working pressure (m3/min) | 3.95/0.7 | 6.6/0.7 | 7.8/0.7 | 10.8/0.7 | 13.8/0.7 | 17.2/0.7 | 21.5/0.7 | 25.6/0.7 | 30.0/0.7 | 34.2/0.7 | 38.6/0.7 | 42.8/0.7 | 45.0/0.7 | 49.2/0.7 | |
3.8/0.8 | 6.4/0.8 | 7.5/0.8 | 10.2/0.8 | 13.2/0.8 | 16.5/0.8 | 20.5/0.8 | 24.0/0.8 | 29.0/0.8 | 33.0/0.8 | 37.0/0.8 | 40.0/0.8 | 43.1/0.8 | 48.0/0.8 | ||
3.2/1.0 | 6.0/1.0 | 7.0/1.0 | 8.8/1.0 | 11.2/1.0 | 15.0/1.0 | 19.0/1.0 | 22.0/1.0 | 26.2/1.0 | 30.0/1.0 | 34.0/1.0 | 36.5/1.0 | 39.5/1.0 | 43.2/1.0 | ||
2.8/1.2 | 4.8/1.2 | 6.2/1.2 | 7.8/1.2 | 10.5/1.2 | 13.0/1.2 | 17.5/1.2 | 19.0/1.2 | 24.5/1.2 | 28.0/1.2 | 32.0/1.2 | 34.0/1.2 | 36.3/1.2 | 40.5/1.2 | ||
Cooling Method | Air Cooled | ||||||||||||||
Discharge Temperature（℃） | Ambient Temperature + 15℃～18℃ | ||||||||||||||
Lubricant（L） | 16 | 18 | 54 | 72 | 90 | 110 | 125 | 150 | |||||||
Noise Level | 65±2 dB(A) | 72±2 dB(A) | 75±2 dB(A) | 82±2 dB(A) | |||||||||||
Driving type | Direct Driven | ||||||||||||||
Motor | Power | 22 | 37 | 45 | 55 | 75 | 90 | 110 | 132 | 160 | 185 | 200 | 220 | 250 | 280 |
Start Method | Y-△ start | ||||||||||||||
Electricity | 380V/50HZ/3P, 415V/50HZ/3P, 220V/60HZ/3P, 460V/60HZ/3P | ||||||||||||||
Dimension L*W*H | 1380 | 1550 | 1550 | 1800 | 2000 | 2200 | 2600 | 2600 | 2700 | 2700 | 2700 | 3200 | 3200 | 3200 | |
800 | 1000 | 1000 | 1150 | 1200 | 1350 | 1450 | 1450 | 1700 | 1700 | 1700 | 1950 | 1950 | 1950 | ||
1300 | 1420 | 1420 | 1650 | 1750 | 1850 | 2000 | 2000 | 2300 | 2300 | 2300 | 2450 | 2450 | 2450 | ||
Weight(kg) | 650 | 900 | 1080 | 1520 | 1880 | 2080 | 2850 | 3220 | 3850 | 4350 | 4500 | 4650 | 5600 | 7900 | |
Air Outlet Pipe Diameter | 1〃 | 1?〃 | 2〃 | DN65 | DN85 | DN100 | |||||||||
Our Service
After-sale Service
1.Any questions or requests before, during or after sales, we would like to help you any time and will find you the best solution in 24 hours.
2. Warranty: Two years for the air-end and One year for the whole machine, spare parts will be provided with best price.
Special Customized Service
1) Full OEM
Quantity: 1 unit is acceptable
In this plan, we will do all the changes (Color, name plate and logo) as your need, and will not charge extra fee.
FAQ
Q1: Are you factory or trade company?
A1: We are factory.
Q2: Warranty terms of your machine?
A2: Two years for the air-end and One year warranty for the complete machine and technical support according to your needs.
Q3: Will you provide some spare parts of the machines?
A3: Yes, of course.
Q4: What about product package?
A4: We pack our products strictly with standard seaworthy case.
Q5: What about the voltage of products? Can they be customized?
A5: Yes, of course. The voltage can be customized according to your equirement.
Q6: Which payment term can you accept?
A6: 30% T/T down payment and 70% T/T balance payment.
Q7: How long will you take to arrange production?
A7: 380V 50HZ we can delivery the goods within 7-15 days. Other voltage will be 30-45 days.
Q8: Can you accept OEM orders?
A8: Yes, with professional design team, OEM orders are highly welcome.
Q9: Which trade term can you accept?
A9: Available trade terms: FOB, CIF, CFR, etc.
