Piston -reciprocating compressors-belt driven



With over 20 years' experience, HighQ Compressor is specialized in manufacturing and marketing piston -reciprocating compressors-belt driven, which is of high efficiency, low energy consumption and long lifespan. As one of the professional manufacturers and suppliers in China, we warmly welcome you to buy quality equipment made in China from our factory.

Basic Info

●Model NO.: HD0208
●Type: Piston –Belt Driven
●Performance: Low Noise
●Drive Mode: Electric
●Power Source: AC Power
●Configuration: Stationary
●Material:  Aluminum
●Piston Type: Closed
●Lubrication Style: Lubricated
●Mute: Not Mute
●Driven Method:  Belt Driven:
●Brand: OEM Can Be Provided
●Trademark: HighQ
●Specification: CE TUV
●Origin: China
●HS Code: 8414809090
Product Description
●With over 20 years of experience at the forefront air compressor manufacturing, the range of products and services that we offer encompasses innovative design with high quality construction backed up with the high level of product support and after sales service.
●This dedication to quality and innovation allows us to deliver the value, reliability, convenience and efficiency that our thousands of customers demand.
●With a warranty and provide a reliable and robust solution for workshop and light industrial applications.
●We mainly export high quality and efficiency air compressors ,our compressors with the advantage of low noise ,energy saving and reliable performance.
Parameter & Specification

Model	Motor Power (kw/hp)	Cylinder (diameter x Piece)	Exhaust volume m3/min	Working Pressure (Mpa)	RPM(r/min)	Dimension (LxWxH cm)	Weight (kg)
HD0208	2.2/3	55x2	0.25	0.7	800	27x27x30	20
HD2055	3/4	65x2	0.36	0.7	820	29x30x39	15
Z-0.036/7	0.55/0.75	51x1	0.005	0.7	800	23x15x27	8
V-0.08/7	0.75/1	51x2	0.08	0.7	800	95x25x31	18
Z-0.10/7	1.5/2	55x1	0.1	0.7	800	27x23x34	20
V-0.12/7	1.1/1.5	51x2	0.12	0.7	800	35x74x29.5	18
V-0.17/7	1.5/2	51x2	0.17	0.7	950	36x25x33	20
V-0.25/7	2.2/3	55x2	0.25	0.7	820	41x27x36	22
W-0.38/7	3/4	65x3	0.58	0.7	800	46.5x27x37	28
V-0.48/7	4/5.5	90x2	0.48	0.7	820	53x30x40	54
W-0.67/7	5.5/7.5	80x3	0.57	0.7	800	52x43x52.5	68
W-0.9/7	7.5/10	90x3	0.9	0.7	800	93.5x43x52.5	73
W-1.4/7	11/15	100x3	1.4	0.7	780	70x62x55	180
W-1.8/7	15/20	120x3	1.8	1.25	780	93x55x110	210
V-0.15/12.5	1.5/2	65x1/51x1	0.15	1.25	950	96x25x32	20
V-0.20/12.5	2.2/3	65x1/51x1	0.2	1.25	820	41x27x36	22
W-0.30/12.5	3/4	65x2/51x1	0.3	1.25	800	46.8x20x38	28
W-0.53/12.5	5.5/7.5	60x2/65x1	0.53	1.25	860	62x42x52.5	68
W-0.71/12.5	7.5/10	50x2/90x1	0.71	1.25	800	62x43x52.8	73
W-1.05/12.5	11/15	100x2/90x1	1.05	1.25	780	76x62x88	130
W-1.50/12.5	16/20	120x2/100x1	1.5	1.25	780	93x56x90	210

With over 20 years' experience, HighQ Compressor is specialized in manufacturing and marketing direct driven piston 0.55kw to 2.2kw, which is of high efficiency, low energy consumption and long lifespan. As one of the professional manufacturers and suppliers in China, we warmly welcome you to buy quality equipment made in China from our factory.
