Refrigerant Type Air Dryer Of HighQ
Xiamen HighQ Compressor Co., Ltd. is one of the leading manufacturers and suppliers of refrigerant type air dryer of highq in China. Please rest assured to buy advanced refrigerant type air dryer of highq made in China from our factory. If you have any enquiry about cooperation, please feel free to email us.
Basic Info
●Model NO.: FN-100FAir Dryer
●Structure: Air Flow Drier
●Operational Method: Continuous
●Operation Pressure: Vacuum Dryer
●Drying Medium: Air
●Heating Mode: Transmission
●Movement Way: Fixed
●Type of Flow: Contra-Flow
●Type of Atomization: Gas Atomization
●Sprayer: Air-Flowing Type
●Performance :Low Noise
Export Markets :Global
●Trademark: HighQ
●Specification: CE TUV
●Origin: China
Technical Data for Air Cooling Refrigerated Air Dryer
| Model | FN-7.5F | FN-10F | FN-15F | FN-20F | FN-30F | FN-50F | FN-75F | FN-100F | FN-150F | FN-200F | FN-300F |
Capacity(m3/min) | 1 | 1.5 | 2 | 2.5 | 3.6 | 6.5 | 8.8 | 12.5 | 20 | 28 | 39 |
Utilization conditions | A、Max. inlet temp.≦80℃ B、Working Ambient≦45℃ C、Max. Working press: 6-10bar(Please inquire for 10 bars and above) | ||||||||||
Dew Point | 1.7℃-5℃ it's atom dew point is equal to -20℃ | ||||||||||
Refrigerant gas | Optional: R-22,R407C,R134A(Enviroment Friendly Freon) | ||||||||||
Compressor (HP) | 1/2 | 1/2 | 3/4HP | 1 | 1-1/2 | 1-3/4 | 3 | 3 | 5 | 5 | 7-1/2 |
Power | AC 220V/50HZ/1P (220V,460V/60HZ available) AC 380V/50HZ/3P (220V,460V/60HZ available) | ||||||||||
Air Inlet/Outlet Dimension（BSP） | 3/4″ | 1″ | 1-1/4″ | 1-1/2″ | 1-1/2″ | 2″ | 2-1/2″ | 3″ | 3″ | 4″ | 4″ |
Length (mm) | 530 | 630 | 750 | 750 | 1000 | 1050 | 1050 | 1150 | 1200 | 1500 | 1800 |
Weight (mm) | 380 | 450 | 480 | 480 | 500 | 600 | 600 | 650 | 650 | 680 | 700 |
Hight (mm) | 660 | 700 | 780 | 830 | 910 | 690 | 1150 | 1270 | 1270 | 1300 | 1400 |
Weight（Kg） | 55 | 73.5 | 75 | 93 | 115 | 198 | 238 | 238 | 248 | 248 | 400 |
