15kw Combined Screw Air Compressor
With over 20 years' experience, HighQ Compressor is specialized in manufacturing and marketing 15kw combined screw air compressor, which is of high efficiency, low energy consumption and long lifespan. As one of the professional manufacturers and suppliers in China, we warmly welcome you to buy quality equipment made in China from our factory.
With over 20 years' experience, HighQ Compressor is specialized in manufacturing and marketing high quality combined air compressor 15kw 8bar, which is of high efficiency, low energy consumption and long lifespan. As one of the professional manufacturers and suppliers in China, we warmly welcome you to buy quality equipment made in China from our factory.
Product Details
With over 20 years' experience, HighQ Compressor is specialized in manufacturing and marketing tank mounted screw stationary air compressor, which is of high efficiency, low energy consumption and long lifespan. As one of the professional manufacturers and suppliers in China, we warmly welcome you to buy quality equipment made in China from our factory.
Basic Info
●Model NO.: HQ-10C
●Type: Compacted Screw air compressor
●Performance: Energy saving , Efficient, Durable
●Drive Mode: Electric
●Power Source: AC Power
●Configuration: Stationary
●Material: Cast Iron
●Lubrication Style: Oil Injection
●Work Pressure ：7-12.5bar
●Export Markets : Global
●Trademark: HighQ
Specification: CE TUV UL ISO 9001：2001
●Origin: China
●HS Code: 8414809090
Product Description
●Variable Frequency Drive makes the machine more efficient and energy saving
●Industrial technology compressors
●High quality in design, components and manufacturing
●Factory tested complete compressed air system use of world class rotary screw elements, designed for continuous operation
●High quality manufacturing standards, CE certificate, German imported Air-end and components make the HQ compressor a highly reliable compressed air system
●We provide rotary compressors with the focus on reliability and energy efficiency allowing our customers to focus on their productivity and profitability.
Technical Specs | ||||||||||||||||||
| Model | Variable Frequency Direct Driven | HQ-7.5C | HQ-10C | HQ-15C | HQ-20C | |||||||||||||
Air Delivery(FAD)/Working Pressure | 0.85/ 7 | 1.3/ 7 | 1.8/ 7 | 2.6/ 7 | ||||||||||||||
0.75/ 8 | 1.2/ 8 | 1.6/ 8 | 2.4/ 8 | |||||||||||||||
0.56/ 10 | 1.0/ 10 | 1.3/ 10 | 2.2/ 10 | |||||||||||||||
0.48/ 13 | 0.8/ 13 | 1.2/ 13 | 1.7/ 13 | |||||||||||||||
Cooling | Cooling Type | Air cooling | ||||||||||||||||
| Discharge Temp-Air End | Environment temp.+15oC | |||||||||||||||||
Motor | Nominal Power | KW | 5.5 | 7.5 | 11 | 15 | ||||||||||||
| Insulation Grade | IP54 | |||||||||||||||||
| Protection Class | F | |||||||||||||||||
| Electrical Entry | v/Hz/Ph | 380v/50hz/3P, 415V/50HZ/3P, 220V/60HZ/3P, 460V/60HZ/3P | ||||||||||||||||
| Start Model | Variable Frequency Drive | |||||||||||||||||
Unit | Max Working Ambient Temp | ℃ | Ambiet Temp.+15℃ | |||||||||||||||
| Noise Level | dB(A) | 62±2 dB(A) | 65±2 dB(A) | |||||||||||||||
| Lubricant Level | L | 12 | 14 | |||||||||||||||
| Drive Model | Variable Frequency Direct Drive | |||||||||||||||||
| Air dryer | Air Delivery m3/min | 1 | 1.5 | 2 | 2.5 | |||||||||||||
| Max.Pressure | Standard 10bar, 13 bars is also available per request | |||||||||||||||||
| Air Tank | L | 500 | ||||||||||||||||
| Oil Residual | PPM | <=3 | ||||||||||||||||
| Particulate Residual | μm | <=3 | ||||||||||||||||
| Length | CM | 190 | 190 | 190 | 190 | |||||||||||||
| Width | CM | 60 | 60 | 60 | 60 | |||||||||||||
| Height | CM | 180 | 180 | 180 | 180 | |||||||||||||
| Unit Weight | KG | 420 | 450 | 750 | 780 | |||||||||||||
| Outlet diameter | Inch | ?" | 1 | |||||||||||||||
With over 20 years' experience, HighQ Compressor is specialized in manufacturing and marketing 7.5hp 10hp 15hp 20hp 5.5kw 7.5kw 11kw 15kw variable frequency direct driven oil-injection compact air compressor for industry, which is of high efficiency, low energy consumption and long lifespan. As one of the professional manufacturers and suppliers in China, we warmly welcome you to buy quality equipment made in China from our factory.
