Xiamen HighQ Compressor Co., Ltd

High quality product, professional service, being the core supplier in compressor industry

Direct Driven Piston 1.5KW To 15KW

Piston, Piston Assy, Piston Assembly manufacturer / supplier in China, offering Engine Piston Basic Info ●Type: Piston –Direct Driven ●Performance: Energy Saving, Low Noise ●Drive Mode: Electric ●Power Source: AC Power ●Configuration: Stationary ●Material: Aluminum ●Piston Type: Closed

Send InquiryChat Now
Product Details

With over 20 years' experience, HighQ Compressor is specialized in manufacturing and marketing direct driven piston 1.5kw to 15kw, which is of high efficiency, low energy consumption and long lifespan. As one of the professional manufacturers and suppliers in China, we warmly welcome you to buy quality equipment made in China from our factory.


Basic Info
●Type: Piston –Direct  Driven
●Performance: Energy Saving, Low Noise
●Drive Mode: Electric
●Power Source: AC Power
●Configuration: Stationary
●Material:  Aluminum
●Piston Type: Closed
●Lubrication Style: Lubricated
●Mute: Not Mute
●Driven Method:  Direct  Driven:
●Brand: OEM Can Be Provided
●Trademark: HighQ
●Specification: CE TUV
●Origin: China
●HS Code: 8414809090
Product Description
●Superior valve and cylinder head design. Precision engineered for efficiency and reliability ●Intercooler, after cooler, large flywheel and unique specially designed shroud ensure cooler operation minimizing wear to valves and cylinders whilst allowing easier removal of downstream condensation
●Dual oil scraper piston rings, efficient air intake filtration and cooler operation provide better quality compressed air
●Oversized roller bearings, high quality materials, robust proven design and solid construction provide durability
Parameter & Specification

Model

Motor Power (kw/hp)

Cylinder
(diameter x Piece)

Exhaust volume
m3/min

Working Pressure (Mpa)

Dimension (LxWxH cm)

Weight (kg)

HD0208/2

0.75/1

42x1

0.1

0.7

47x27x47

21

HD0208/3

0.75/1

42x1

0.1

0.7

47x27x47

21

HD47L/1

1.5/2

47x1

0.12

0.7

60x31x58

27

HD47L/3

1.5/2

47x1

0.12

0.7

60x31x58

27

HD47L/4

1.5/2

47x1

0.12

0.7

60x31x58

27

HD47L/5

1.5/2

47x1

0.12

0.7

60x31x58

27

HDW202/5

1.5/2

61x1

0.196

0.7

60x30x59

24

HD030/1

1.876/3

47x1

0.12

0.7

70x30x58

32

HD030/2

2.2/3

42x2

0.2

0.7

68x32x62

36

HD030/5

1.5/2.5

47x1

0.12

0.7

80x32x57

37

HD020/9

2.2/3

55x2

0.25

0.7

66x35x55

36

HD030/9

3.0/4

65x2

0.36

0.7

58x48x84

111

With over 20 years' experience, HighQ Compressor is specialized in manufacturing and marketing belt driven piston 1.5kw to 15kw, which is of high efficiency, low energy consumption and long lifespan. As one of the professional manufacturers and suppliers in China, we warmly welcome you to buy quality equipment made in China from our factory.







Hot Tags: direct driven piston 1.5kw to 15kw, China, manufacturers, suppliers, factory, buy, made in China
